This panel-mount current sensor relay is for electrical professionals who need to sense and control loads up to 20 amps. It combines current sensing and relay control in one unit, helping simplify installations without an external current ring.
The unit has a fixed current-sensing trigger point, a 20A load capacity, SPDT relay configuration, and 24 VAC/DC operation. It measures 4 in. wide by 2.95 in. deep by 1.25 in. high.
Key Features:
Choose this panel-mount relay for applications requiring fixed current sensing and SPDT control of loads up to 20 amps on 24 VAC/DC systems.
| Country of Origin: | US |
| Product Depth: | 4" |
| Product Height: | 1.25" |
| Product Type: | Panel |
| Product Width: | 2.95" |
| Quantity Included: | 1 |
| Shipping Weight: | 41 lbs |
| Manufacturer Part Number: | RIBMX24BF |
| Length: | 2.95 in |
| Width: | 4 in |
| Height: | 1.25 in |
| Amperage: | 20 A |
| Brand: | RIB |
| Contact Type: | SPDT |
| Description: | Panel Internal Current Transducer W/Relay |
| Expected Relay Life: | 10 Million Cycles Minimum Mechanical |
| Humidity Range: | 5 To 95 Percent (Noncondensing) |
| Manufacturers Part Number: | RIBMX24BF |
| Number of Relays: | 1 |
| Operating Temperature: | -30° To 140°F |
| Threshold: | Fixed |
| Voltage: | 24VAC/DC V |
| Warranty: | 1 yr |
| Certifications: | UL/cUL |
| Width: | 4.00 in |
| Height: | 1.25 in |
| Depth: | 2.95 in |
No additional information available.
