Roof Ventilators

Roof ventilators are exhaust fans used to move air out of commercial and industrial buildings. They are commonly used in restaurants, offices, warehouses, factories, and other commercial spaces, with roof- or wall-mount options represented for ventilation layouts that require building exhaust.

Product Display:
Helpful Buying Guide

Roof Ventilator Buying Guide

Compare roof ventilators by airflow, exhaust direction, drive type, mounting arrangement, and compatible electrical service. The products represented here include upblast and downblast exhausters for commercial facilities, with airflow capacities from 1,051 to 6,202 CFM.

Visual Guide

Popular examples in this category

Use Cases

Exhaust air from commercial spaces

These roof ventilators are used to remove air from restaurants, offices, warehouses, factories, and other commercial buildings.

How to Choose

Match airflow and installation needs

Start with the listed CFM capacity, then compare upblast or downblast operation, roof or wall mounting compatibility, drive type, and the electrical configuration required for the installation.

Applications

Support roof or wall exhaust layouts

Many represented units can be installed on a roof or wall, helping facility teams fit an exhaust fan to compatible building ventilation layouts.

Additional Information

Review access and control features

Selected models include quick-release latches for motor access, bird screens, backward-inclined wheels, and EC variable-speed motors with adjustment or remote-control compatibility.

1,051–6,202CFM range

Listed airflow capacities across representative products.

2Exhaust directions

Upblast and downblast designs are represented.

2Mounting approaches

Roof and wall mounting are represented on many models.

44 x 44 x 39 in.Listed unit size

Dimensions provided for one 3,880 CFM belt-drive upblast exhauster.

Comparison Guide

Compare Roof Ventilator Configurations

Use this overview to compare the two exhaust directions represented in the category. Always review the individual product listing for its specific drive, mounting, airflow, and electrical details.

Selection FactorUpblast Roof ExhausterDownblast Roof Exhauster
Exhaust directionDirects exhausted air upward.Directs exhausted air downward.
Drive types representedBelt-drive models are represented; a direct-drive upblast model is also represented.Direct-drive and belt-drive models are represented.
Listed airflow examples1,051 to 6,202 CFM among represented upblast products.1,544 to 3,400 CFM among represented downblast products.
Mounting representedRoof or wall mounting is listed on represented products.Roof or wall mounting is listed on represented products.
Planning Guide

Plan the right fit before choosing

Start With Airflow

Choose a CFM range that fits the exhaust application

The listed roof ventilators span a broad range of exhaust-air capacities. Lower listed capacities include 1,051, 1,285, and 1,544 CFM, while other represented options provide 2,400, 2,466, 2,529, 3,067, 3,400, 3,880, 4,771, and 6,202 CFM.

  • Compare the unit's listed CFM with the airflow needed for the space.
  • Use the product listing to confirm the specific airflow capacity.
  • Consider whether adjustable EC variable-speed operation is needed for setup and balancing.
Select Exhaust and Drive Configuration

Compare upblast, downblast, belt-drive, and direct-drive designs

Upblast roof exhausters direct exhausted air upward, while downblast designs direct it downward. The category includes both belt-drive and direct-drive units. Certain downblast models also list backward-inclined wheels for non-overloading wheel operation.

  • Choose upblast when an upward exhaust direction is required.
  • Choose downblast when the listed downward exhaust direction fits the application.
  • Compare belt-drive and direct-drive configurations listed for the model.
  • Look for quick-release latches where easier motor access is a priority.
Confirm Mounting and Power

Check site compatibility before selecting a fan

Roof mounting is represented throughout the category, and many listed units are also compatible with wall mounting. Electrical configurations vary across products, including 115V single-phase, 120/240V single-phase, 230/460V, and 575V options.

  • Confirm whether the planned location requires roof mounting or wall mounting.
  • Match the fan to a compatible electrical system.
  • Review listed motor horsepower where it is provided.
  • Use listed dimensions when installation space planning is needed.
FAQ

Common questions before buying

What are roof ventilators used for?

They remove air from commercial and industrial spaces such as restaurants, offices, warehouses, factories, and other commercial buildings.

What is the difference between upblast and downblast roof exhausters?

Upblast units direct exhausted air upward, while downblast units direct exhausted air downward.

Can these roof ventilators be wall mounted?

Many represented products list roof or wall mounting compatibility. Check the individual model before selecting.

What airflow capacities are represented?

Representative products range from 1,051 to 6,202 CFM.
