Enclosed 30A SPST power relay for 24VAC/DC control

Enclosed 30A Power Relay, 24VAC/DC

SKU:
WBB1034327
Our Price:
$90.94
BBB Accredited Business Badge
Free Shipping on Qualifying Orders Over $99
Shipping & Availability:
  • Fast Shipping: Estimated delivery in 3-6 Business Days
  • Bulk Pricing Available: Call 800-810-FILE or email us for a custom quote.
✔ Secure Checkout
✔ Business Purchasing Support
✔ 5.0 Google Store Rating
Product Specifications:
Country of Origin: US
Product Depth: 3.2"
Product Height: 1.8"
Product Type: Relays
Product Width: 2.3"
Quantity Included: 1
Shipping Weight: 73 lbs
Manufacturer Part Number: RIB24Z
Length: 2.3 in
Width: 3.2 in
Height: 1.8 in
Wire Size: 16 in
(No reviews yet) Write a Review
Adding to cart… The item has been added
✔ Fast Shipping · ✔ Secure Checkout · ✔ Made in USA
Questions? We're here to help.
Call 800-810-FILE or email us .
Free Shipping on Qualifying Orders Over $99
Product Specifications:
Country of Origin: US
Product Depth: 3.2"
Product Height: 1.8"
Product Type: Relays
Product Width: 2.3"
Quantity Included: 1
Shipping Weight: 73 lbs
Manufacturer Part Number: RIB24Z
Length: 2.3 in
Width: 3.2 in
Height: 1.8 in
Wire Size: 16 in

This enclosed power relay is for electrical installers and control-system professionals who need to switch circuits using a 24VAC/DC control input. It provides normally open and normally closed SPST contacts in a packaged relay assembly for control-panel and electrical applications.

The relay is rated for 30A and operates on 24VAC/DC. Its SPST-NO and SPST-NC contact configuration provides one normally open and one normally closed switching option. The enclosed assembly includes the relay, LED indicator, socket, mounting rail, transient protection, and housing. It measures 3.2 in. wide, 2.3 in. deep, and 1.8 in. high.

Key Features:

  • 30A rating: Supports switching applications requiring a 30A power relay.
  • 24VAC/DC operation: Works with 24VAC or 24VDC control power.
  • SPST-NO and SPST-NC contacts: Provides both normally open and normally closed switching options.
  • Enclosed packaged assembly: Combines key relay components in one unit rather than requiring separate on-site assembly.
  • LED indicator: Provides a visible relay status indication.

Choose this enclosed relay when a 30A, 24VAC/DC-operated unit with SPST normally open and normally closed contacts fits your electrical control requirements.

Country of Origin: US
Product Depth: 3.2"
Product Height: 1.8"
Product Type: Relays
Product Width: 2.3"
Quantity Included: 1
Shipping Weight: 73 lbs
Manufacturer Part Number: RIB24Z
Length: 2.3 in
Width: 3.2 in
Height: 1.8 in
Wire Size: 16 in
Amperage: 30 A
Brand: RIB
Contact Type: 1 SPST N/O, 1 SPST N/C
Description: Enclosed Power Relay
Expected Relay Life: 10 Million Cycles Minimum Mechanical
Humidity Range: 5 To 95 Percent (Noncondensing)
Manufacturers Part Number: RIB24Z
Number of Relays: 1
Operating Temperature: -30° To 140°F
Voltage: 24VAC/DC V
Wire Rating: 600V
Warranty: 1 yr
Certifications: UL/cUL
Width: 3.20 in
Height: 1.80 in
Depth: 2.30 in
!
