Data Logging Vane Thermo-Anemometer

This data logging vane thermo-anemometer helps technicians and facility professionals measure air velocity and air temperature while documenting readings for review. It also provides contact temperature measurement for inspection and monitoring tasks.

The instrument uses a low-friction, ball-bearing rotating vane probe and a thermistor sensor for air temperature readings. It measures air velocity in FPM, m/s, KPH, MPH, and knots, and supports contact temperature measurement with optional Type J or K thermocouples. An integrated SD card logger supports manual recording of up to 99 readings or automatic sampling intervals from 1 to 3,600 seconds; SD card capacity is up to 16 GB. Recorded raw data can be generated as an Excel file without software.

Key Features:

• Air velocity measurement: Supports airflow readings in multiple selectable units for flexible field measurement.
• Air and contact temperature capability: Measures air temperature and supports contact temperature checks with optional Type J or K thermocouples.
• Integrated SD data logging: Records readings manually or at selected intervals for documentation and analysis.
• Backlit LCD: Makes readings easier to view in low-light work areas.
• Data hold and Min/Max functions: Helps users capture current readings and review measurement extremes.
• Automatic temperature compensation: Supports compensated air velocity measurements.

Choose this vane thermo-anemometer for air velocity, air temperature, and contact temperature measurement with onboard data logging. It includes a vane probe, hard carrying case, and batteries.
