Finned 240V strip heater with end-mounted bolt terminals

Finned Strip Heater, 240V, 1900W, 21 in. L

SKU:
WBB3151210
Model/MPN:
FS2062
Our Price:
$199.94
BBB Accredited Business Badge
Free Shipping on Qualifying Orders Over $99
Shipping & Availability:
  • Fast Shipping: Estimated delivery in 3-6 Business Days
  • Bulk Pricing Available: Call 800-810-FILE or email us for a custom quote.
✔ Secure Checkout
✔ Business Purchasing Support
✔ 5.0 Google Store Rating
Product Specifications:
Country of Origin: CA
Material: Aluminum
Product Depth: 4"
Product Height: 4"
Product Type: Strip Heaters
Product Width: 17"
Quantity Included: 1
Voltage: 240 V
Manufacturer Part Number: FS2062
Length: 21 in
Width: 1-1/2 in
Screw Size: 10 - 32
Slotted Hole Length: 5/8 in
Slotted Hole Width: 9/32 in
Brand: Caloritech
Fin Material: Steel
Manufacturers Part Number: FS2062
Max Exposure Temperature: 1000 °F
Sheath Material: Aluminum Steel
Type: Strip Heater
Watt Density: 29.8 W
Wattage: 1900 W
Watts High: 1900 W
Warranty: 1
Certifications: CSA, UL Safety
(No reviews yet) Write a Review
Adding to cart… The item has been added
✔ Fast Shipping · ✔ Secure Checkout · ✔ Made in USA
Questions? We're here to help.
Call 800-810-FILE or email us .
Free Shipping on Qualifying Orders Over $99
Product Specifications:
Country of Origin: CA
Material: Aluminum
Product Depth: 4"
Product Height: 4"
Product Type: Strip Heaters
Product Width: 17"
Quantity Included: 1
Voltage: 240 V
Manufacturer Part Number: FS2062
Length: 21 in
Width: 1-1/2 in
Screw Size: 10 - 32
Slotted Hole Length: 5/8 in
Slotted Hole Width: 9/32 in
Brand: Caloritech
Fin Material: Steel
Manufacturers Part Number: FS2062
Max Exposure Temperature: 1000 °F
Sheath Material: Aluminum Steel
Type: Strip Heater
Watt Density: 29.8 W
Wattage: 1900 W
Watts High: 1900 W
Warranty: 1
Certifications: CSA, UL Safety

This finned strip heater is an industrial heating component for users who need heat for surfaces or process air. It provides 1900W of heating output for applications such as heating platens, dies, molds, tanks, piping, and drying equipment.

The heater operates at 240V and measures 21 inches long. Its assembly is enclosed in an aluminized steel sheath, and it has 0.022-inch-thick cadmium-plated steel fins at a nominal density of four fins per inch. Two offset bolt-type terminals are located at one end, and mounting holes support secure installation. The maximum sheath temperature is 1000°F (538°C).

Key Features:

  • 1900W output: Provides substantial heating capacity for industrial surface and process-air heating needs.
  • Finned construction: Adds heat-transfer surface area through closely spaced steel fins.
  • 240V operation: Matches 240V electrical heating systems.
  • Bolt-type terminals: Supports electrical connection from one end of the heater.
  • Mounting holes: Helps secure the heater to a wall or housing during installation.
  • Aluminized steel sheath: Encloses the heater assembly and provides corrosion resistance.

Choose this 21-inch finned strip heater for 240V industrial heating installations that require 1900W output, end-mounted terminals, and a securely mountable component design.

Country of Origin: CA
Material: Aluminum
Product Depth: 4"
Product Height: 4"
Product Type: Strip Heaters
Product Width: 17"
Quantity Included: 1
Voltage: 240 V
Manufacturer Part Number: FS2062
Length: 21 in
Width: 1-1/2 in
Screw Size: 10 - 32
Slotted Hole Length: 5/8 in
Slotted Hole Width: 9/32 in
Brand: Caloritech
Fin Material: Steel
Manufacturers Part Number: FS2062
Max Exposure Temperature: 1000 °F
Sheath Material: Aluminum Steel
Type: Strip Heater
Watt Density: 29.8 W
Wattage: 1900 W
Watts High: 1900 W
Warranty: 1
Certifications: CSA, UL Safety
Width: 4.00 in
Height: 4.00 in
Depth: 17.00 in
!
