Precision Pin Gage Set, 0.061–0.250 in.

This precision pin gage set helps inspectors, machinists, and quality teams check small hole sizes, evaluate slots, and locate hole distances. It provides a practical selection of gage pins for detailed dimensional inspection work.

The set covers sizes from 0.061 to 0.250 inch in 0.001-inch increments. Each 2-inch-long pin is centerless lapped, etched with its size, hardened to RC 60/67, and made to a 0.0002-inch tolerance. A color-coded adjustable go/no-go gage handle and a high-impact protective case with marked pin locations are included.

Key Features:

• 0.061–0.250 in. range: Supports measurement of small holes across a defined size range.
• 0.001 in. increments: Helps users make precise size checks between adjacent gage sizes.
• 0.0002 in. tolerance: Provides a consistent basis for dimensional inspection.
• Etched, centerless-lapped pins: Makes individual pin sizes easy to identify while supporting smooth measuring surfaces.
• Adjustable go/no-go handle: Allows users to hold pins securely during inspection.
• Marked protective case: Keeps gages organized and helps users return each pin to its designated location.

Choose this pin gage set for small-hole and slot inspection where closely spaced sizes, clearly identified pins, and organized storage are needed.
