This metric shoulder eye bolt is for commercial buyers and maintenance or fabrication teams that need a threaded eye connection point in compatible metric-threaded equipment or assemblies.
The eye bolt is drop forged from carbon steel with a self-colored finish. It has an M22 x 2.50 fully threaded ISO coarse Thread-6G shank and a shoulder-pattern design. One eye bolt is included.
Key Features:
Choose this eye bolt when your application calls for an M22 x 2.50, fully threaded shoulder-pattern eye bolt with ISO coarse Thread-6G threading.
| Country of Origin: | Made in USA |
| Material: | Steel |
| Product Depth: | 9" |
| Product Height: | 7" |
| Product Type: | Eye Bolts |
| Product Width: | 9" |
| Quantity Included: | 1 |
| Shipping Weight: | 2.11 lbs |
| Manufacturer Part Number: | M22 |
| Eye Inside Dimension: | 46mm |
| Eye Outside Dimension: | 90.4mm |
| Rated Weight Capacity: | 6292 lbs |
| Shank Length: | 63.5mm in |
| Thread Size: | M22 x 2.50 in |
| Brand: | Ken Forging |
| Manufacturers Part Number: | M22 |
| Pattern: | Shoulder |
| Width: | 9.00 in |
| Height: | 7.00 in |
| Depth: | 9.00 in |
