Enclosed dry contact input relay with 120-277 VAC input and 10A SPDT contacts

Enclosed Dry Contact Input Relay, 120-277 VAC, 10A SPDT - Model RIB21CDC

SKU:
WBB1034051
Our Price:
$38.94
BBB Accredited Business Badge
Free Shipping on Qualifying Orders Over $99
Shipping & Availability:
  • Fast Shipping: Estimated delivery in 3-6 Business Days
  • Bulk Pricing Available: Call 800-810-FILE or email us for a custom quote.
✔ Secure Checkout
✔ Business Purchasing Support
✔ 5.0 Google Store Rating
Product Specifications:
Country of Origin: US
Product Depth: 2.8"
Product Height: 1.5"
Product Type: Relays
Product Width: 1.7"
Quantity Included: 1
Shipping Weight: 342 lbs
Manufacturer Part Number: RIB21CDC
Length: 1.7 in
Width: 2.8 in
Height: 1.5 in
Wire Size: 16 in
(No reviews yet) Write a Review
Adding to cart… The item has been added
✔ Fast Shipping · ✔ Secure Checkout · ✔ Made in USA
Questions? We're here to help.
Call 800-810-FILE or email us .
Free Shipping on Qualifying Orders Over $99
Product Specifications:
Country of Origin: US
Product Depth: 2.8"
Product Height: 1.5"
Product Type: Relays
Product Width: 1.7"
Quantity Included: 1
Shipping Weight: 342 lbs
Manufacturer Part Number: RIB21CDC
Length: 1.7 in
Width: 2.8 in
Height: 1.5 in
Wire Size: 16 in

This enclosed dry contact input relay is designed for electrical and controls professionals who need to use a dry-contact signal to operate a separate load. It provides a self-powered Class 2 input for activation when the dry contact closes, helping connect controllers and switching devices within relay control applications.

The relay operates on 120-277 VAC input power and has a 10A SPDT contact configuration. Its dry-contact input can be activated by thermostats, switches, other relays, and solid-state switches. Relay contacts are isolated from both the input power and dry-contact input, allowing them to be wired for another power or low-voltage load. The enclosure measures 2.8 in. x 1.7 in. x 1.5 in.

Key Features:

  • Dry-contact activation: Allows the relay to be triggered by compatible dry-contact control devices.
  • Self-powered Class 2 input: Provides the low-voltage power needed to activate the relay when the input contact closes.
  • 120-277 VAC operation: Supports operation across a broad AC input-voltage range.
  • Isolated relay contacts: Helps separate the switched circuit from the input power and control input.
  • SPDT, 10A contacts: Provides a single-pole, double-throw switching configuration for compatible loads.
  • Enclosed design: Keeps the relay contained in a compact 2.8 in. x 1.7 in. x 1.5 in. enclosure.

Choose this relay for control setups that use a dry-contact input and require isolated SPDT switching with 120-277 VAC input operation.

Country of Origin: US
Product Depth: 2.8"
Product Height: 1.5"
Product Type: Relays
Product Width: 1.7"
Quantity Included: 1
Shipping Weight: 342 lbs
Manufacturer Part Number: RIB21CDC
Length: 1.7 in
Width: 2.8 in
Height: 1.5 in
Wire Size: 16 in
Amperage: 10 A
Brand: RIB
Contact Type: SPDT
Description: Dry Contact Input Relay
Expected Relay Life: 10 Million Cycles Minimum Mechanical
Humidity Range: 5 To 95 Percent (Noncondensing)
Manufacturers Part Number: RIB21CDC
Motor Horsepower: 1/2 HP
Number of Relays: 1
Operating Temperature: -30° To 140°F
Voltage: 120-277VAC V
Wire Rating: 600V
Warranty: 1 yr
Certifications: UL/cUL
Width: 2.80 in
Height: 1.50 in
Depth: 1.70 in
!
