This outside micrometer is a precision measuring tool for professionals who need to check external dimensions on workpieces. It measures within a 7–8 inch range for inspection and measurement tasks.
The micrometer has a 7–8 inch measuring range, with graduations of 0.0001 inch in imperial units and 0.01 mm in metric units. It features carbide measuring tips and includes setting standards and a fitted storage case.
Key Features:
Choose this outside micrometer for external measurement work requiring a 7–8 inch range, dual imperial and metric graduations, and carbide measuring tips.
| Country of Origin: | CN |
| Product Depth: | 9.843 |
| Product Height: | 1.378 |
| Product Type: | Micrometers |
| Product Width: | 16.535 |
| Quantity Included: | 1 |
| Manufacturer Part Number: | 3203-8A |
| Dimension A: | .764" |
| Dimension B: | 4.606" |
| Dimension L: | 8.228" |
| Metric or Inch: | Inch in |
| Min Measurement: | 7 in |
| Min Outside Diameter: | 7 in |
| Range: | 7-8 |
| Resolution/Graduation: | 0.0001 in |
| Accuracy: | 0.00028 IN °F |
| Anvil Shape: | Flat |
| Case: | Yes |
| Data Output: | No |
| Description: | Outside Micrometer |
| Digital: | No |
| Digital Counter: | No |
| Fraction Option: | No |
| IP Rating: | None |
| Manufacturers Part Number: | 3203-8A |
| Measuring Face Material: | Carbide |
| Mechanical Or Digital: | Mechanical |
| Power Source: | None |
| Rotating Spindle: | Yes |
| Series: | 3203 |
| Style: | General Purpose |
| Thimble Type: | Ratchet Stop |
| Type: | Outside Micrometer |
| Long Form Calibration Certificate Included: | No |
| Shipping Method: | Parcel |
| Width: | 9.84 in |
| Height: | 1.38 in |
| Depth: | 16.54 in |
