This extra-deep pushbutton enclosure is designed for electricians and control-panel builders who need to house pushbuttons or switches. It provides a two-hole mounting location for compatible controls while allowing added room for pushbutton contact blocks.
The gray steel enclosure has two factory-stamped four-way pushbutton holes for 30.5 mm and 22.5 mm pushbuttons and switches. Its extra-deep design accommodates additional contact blocks. Features include continuously welded, smooth-ground seams, captive cover screws that thread into sealed wells, a grounding nut in the enclosure body, a cover bonding provision, an oil-resistant gasket, and external wall-mounting brackets. Overall dimensions are 7 in. wide, 5 in. deep, and 4.25 in. high.
Key Features:
Choose this enclosure for two compatible pushbutton or switch controls when extra internal depth is needed for contact blocks and wall mounting is preferred.
| Color/Finish: | Gray |
| Country of Origin: | CN |
| Material: | Steel |
| Product Depth: | 5" |
| Product Height: | 4.25" |
| Product Type: | Steel Boxes |
| Product Width: | 7" |
| Quantity Included: | 1 |
| Shipping Weight: | 3.6 lbs |
| Manufacturer Part Number: | E2PBX |
| Color: | Gray |
| A x B x C: | 6 x 4 x 4-3/4 |
| Dimension T: | 3.75 in |
| Dimension Y: | 1.98 in |
| Gauge: | 14 ga |
| Hole Size: | 30.5 mm in |
| Mounting G x H: | 6.50 x 3.12 in |
| Overall L x W: | 7.00 x 4.22 in |
| Brand: | Hoffman |
| Description: | Extra-Deep 30.5-mm & 22.5-mm Pushbutton Enclosures |
| Manufacturers Part Number: | E2PBX |
| Number of Holes: | 2 |
| Type: | 12 |
| Width: | 5.00 in |
| Height: | 4.25 in |
| Depth: | 7.00 in |
No additional information available.
This extra-deep steel pushbutton enclosure is for installers and control-panel builders mounting pushbuttons and switches. It provides additional interior depth for configurations that require extra...
This single-pushbutton enclosure gives electricians and panel builders a dedicated housing for a pushbutton or switch. It is designed to organize and protect a control-device installation in...
This six-position pushbutton enclosure provides a mounting location for operators installing pushbuttons and switches in control applications. It helps organize compatible controls in a protected...
