This 30-inch wall-mount circulator fan is designed for facility managers and maintenance teams who need to circulate air from a fixed wall location. Its three speed settings let users adjust airflow for day-to-day cooling and ventilation needs.
The fan operates on 120V single-phase power and has a 1/4 HP, 2.4-amp permanently lubricated ball-bearing motor with a permanent split capacitor. It uses three aluminum paddle blades on a steel hub and spider assembly. A 9-foot, three-conductor SJT cord with a three-prong plug connects to grounded electrical outlets. Overall dimensions are 33.5 inches wide, 40 inches deep, and 7 inches high.
Key Features:
Choose this wall-mount circulator fan for fixed-location air movement with adjustable three-speed operation, 120V single-phase power, and a grounded plug connection.
| Airflow (CFM): | 4,200 CFM |
| Color/Finish: | Black |
| Country of Origin: | CN |
| Material: | Steel / Aluminum |
| Motor: | 1/4 HP |
| Number of Speeds: | 3 |
| Phase: | 1 |
| Product Depth: | 33.5" |
| Product Height: | 7" |
| Product Type: | Wall Fans |
| Product Width: | 40" |
| Quantity Included: | 1 |
| Voltage: | 120 V |
| Manufacturer Part Number: | CACU30W |
| Color: | Black |
| Weight: | 35 lbs |
| Cord Length: | 9 ft |
| Fan Diameter: | 30 in |
| Amperage: | 2.5 A |
| Assembly Required: | Yes |
| Blade Type: | Aluminum |
| Brand: | TPI |
| CFM: | 3500/4200 CFM |
| CFM High: | 4200 CFM |
| Drive Type: | Direct Drive |
| Fan Type: | Commercial |
| Features: | Pull Chain Switch |
| For Use With: | Spot & People Cooling |
| Hertz: | 60 Hz |
| Horsepower: | 1/4 HP |
| Indoor/Outdoor: | Indoor |
| Manufacturers Part Number: | CACU30W |
| Motor Type: | Open Air Over |
| Mounting Location: | Wall |
| Number of Blades: | 3 |
| Oscillating/Non Oscillating: | Non Oscillating |
| Power Cord Type: | SJT 3 Conductor |
| RPM: | 1100 rpm |
| Wattage: | 300 W |
| Warranty: | 1 yr |
| Certifications: | UL, cUL Listed, OSHA compliant |
| Width: | 33.50 in |
| Height: | 7.00 in |
| Depth: | 40.00 in |
