Gray fabric duct straight section with vent holes

16-Inch Gray Fabric Duct Straight Section with Vents, 500 CFM

SKU:
WBB572208
Our Price:
$355.94
BBB Accredited Business Badge
Free Shipping on Qualifying Orders Over $99
Shipping & Availability:
  • Fast Shipping: Estimated delivery in 3-6 Business Days
  • Bulk Pricing Available: Call 800-810-FILE or email us for a custom quote.
✔ Secure Checkout
✔ Business Purchasing Support
✔ 5.0 Google Store Rating
Product Specifications:
Airflow (CFM): 500 CFM
Color/Finish: Gray
Country of Origin: DK
Product Depth: 15"
Product Height: 10"
Product Type: Fabric Ducts
Product Width: 23"
Quantity Included: 1
Shipping Weight: 4 lbs
Manufacturer Part Number: 450116730141
Color: Gray
Length: 10 ft
(No reviews yet) Write a Review
Adding to cart… The item has been added
✔ Fast Shipping · ✔ Secure Checkout · ✔ Made in USA
Questions? We're here to help.
Call 800-810-FILE or email us .
Free Shipping on Qualifying Orders Over $99
Product Specifications:
Airflow (CFM): 500 CFM
Color/Finish: Gray
Country of Origin: DK
Product Depth: 15"
Product Height: 10"
Product Type: Fabric Ducts
Product Width: 23"
Quantity Included: 1
Shipping Weight: 4 lbs
Manufacturer Part Number: 450116730141
Color: Gray
Length: 10 ft

This gray fabric duct straight section is for HVAC professionals and facility teams assembling a fabric duct run. It distributes air through vent openings along the section while connecting between adjacent duct components.

The 10-foot straight section has a 16-inch diameter and is sized for 500 CFM at 0.25-inch W.G. system static pressure. Laser-cut holes run the length of the duct at the 4 and 8 o’clock positions. Built-in zippers connect the section to preceding and following components, and fabric loops accommodate cable hooks. A complete run requires suspension hardware, an inlet section, and an endcap.

Key Features:

  • Laser-cut vent holes: Provides airflow openings along the full length of the section.
  • Built-in zipper connections: Allows the section to join with adjacent duct components.
  • Fabric cable loops: Provides attachment points for cable hooks.
  • 500 CFM sizing: Supports duct runs designed for 500 CFM at 0.25-inch W.G. system static pressure.

Choose this 10-foot gray straight section for a compatible 16-inch fabric duct run that needs lengthwise venting and zipper-connected assembly.

Airflow (CFM): 500 CFM
Color/Finish: Gray
Country of Origin: DK
Product Depth: 15"
Product Height: 10"
Product Type: Fabric Ducts
Product Width: 23"
Quantity Included: 1
Shipping Weight: 4 lbs
Manufacturer Part Number: 450116730141
Color: Gray
Length: 10 ft
Weight Capacity: 4 & 5 tons
Weight: 4 lbs
Diameter: 16 in
Static Pressure Loss @ 0.25" Wg: 500
Brand: Zip-A-Duct
Features: Machine Washable
Manufacturers Part Number: 450116730141
Material: Permeable Fabric
Max CFM per Diameter: 2000 CFM
Min CFM Per Diameter: 1201 CFM
Static Pressure Loss @ 0.50" Wg: 1000
Type: Straight Sections
Certifications: UL Listed
Width: 15.00 in
Height: 10.00 in
Depth: 23.00 in
!
