120V AC Outlet Circuit Analyzer

This outlet circuit analyzer helps electricians, maintenance teams, and facility technicians check wiring conditions at compatible electrical outlets. It provides clear test results to support troubleshooting and inspection work.

Designed for North American 120V AC 3-wire outlets, this analyzer identifies common wiring faults, including dual open-neutral and open-ground conditions. It displays AC line voltage, tests AFCI and GFCI devices with time-to-trip results, and performs voltage-drop testing at 12A, 15A, and 20A loads. A large color LCD presents results, while the detachable cord supports storage. The unit automatically powers off after 5 minutes of inactivity and carries a CAT III 135V safety rating.

Key Features:

• Color LCD display: Makes test results easier to read and interpret during outlet checks.
• Wiring fault detection: Helps identify common outlet wiring issues, including open-neutral and open-ground faults.
• AFCI and GFCI testing: Supports inspection of standard AFCI and GFCI electrical outlets with time-to-trip information.
• Voltage-drop testing: Allows testing at 12A, 15A, and 20A current loads for additional circuit evaluation.
• Automatic power-off: Conserves battery life after 5 minutes without activity.

A practical choice for teams maintaining and inspecting compatible 120V AC outlets, this circuit analyzer combines wiring checks, protective-device testing, and voltage-drop testing in one tool.
