Class 2 Signaling Transformer, 120V AC to 8V AC

This Class 2 signaling transformer supplies low-voltage 8V AC power from a 120V AC input. It is designed for residential, commercial, and industrial users who need a low-voltage power source for signaling equipment.

The transformer has a 120V AC primary and 8V AC secondary. It features non-regenerative thermal overload protection, a grounding wire, pre-stripped pigtails, and screw terminals on the secondary. It mounts in a standard 1/2-inch knockout or surface mounts with the included foot mounts, and it is suitable for plastic or metal back boxes. It can also be used with a compatible transformer plate for enclosed installation in a standard two-gang outlet box. Overall dimensions are 2.5 inches wide, 2.5 inches deep, and 2.5 inches high.

Key Features:

• 8V AC secondary: Provides low-voltage AC output from a 120V AC primary connection.
• Flexible mounting options: Supports standard 1/2-inch knockout mounting or surface mounting with included foot mounts.
• Back box compatibility: Can be installed in either plastic or metal back boxes.
• Pre-stripped pigtails: Helps simplify electrical connections during installation.
• Secondary screw terminals: Provides a direct connection point for secondary wiring.
• Thermal overload protection: Adds non-regenerative overload protection to the transformer.

Choose this compact Class 2 transformer when your signaling installation requires 120V AC input and 8V AC low-voltage output, with knockout, surface, or back-box mounting options.
