These Belleville disc springs are for commercial buyers and maintenance professionals who need spring-like action in heavy-load applications. Their curved disc form provides a compact spring component for fastening and assembly needs.
Each carbon steel disc spring measures 1.125 in. outside diameter, 0.38 in. inside diameter, and 0.053 in. thick, with a 0.08 in. overall height. The pack includes 12 springs. The curved construction enables spring-like operation.
Key Features:
Choose these carbon steel Belleville disc springs when your application calls for a curved spring component with the listed diameter, thickness, and overall-height dimensions.
| Country of Origin: | Made in USA |
| Material: | 1074 Carbon Steel |
| Product Depth: | 2.5" |
| Product Height: | 0.14" |
| Product Type: | Belleville Springs |
| Product Width: | 3.5" |
| Quantity Included: | 1 |
| Shipping Weight: | 15 lbs |
| Surface Thickness: | 0.053" |
| Manufacturer Part Number: | MB1125-053 |
| Height: | 0.08 in |
| Deflection at Load: | 0.014" |
| Flat Load: | 535 lbs. |
| Load at Deflection: | 254 - 344 lbs. |
| Max Outside Dimension: | 1.125" |
| Min Inside Dimension: | 0.38" |
| Nominal Rod Size: | 0.375" |
| Thickness: | 0.053" |
| Unit of Measurement: | Inch (Imperial) |
| Brand: | Gardner Spring |
| Description: | Belleville Disc Spring |
| Finish: | Plain |
| Manufacturers Part Number: | MB1125-053 |
| Package Quantity: | 12 |
| Width: | 2.50 in |
| Height: | 14.00 in |
| Depth: | 3.50 in |
