24-inch counterbalanced automatic exhaust shutter

24-Inch Counterbalanced Exhaust Shutter

SKU:
WBB484674
Our Price:
$149.94
BBB Accredited Business Badge
Free Shipping on Qualifying Orders Over $99
Shipping & Availability:
  • Fast Shipping: Estimated delivery in 3-6 Business Days
  • Bulk Pricing Available: Call 800-810-FILE or email us for a custom quote.
✔ Secure Checkout
✔ Business Purchasing Support
✔ 5.0 Google Store Rating
Product Specifications:
Country of Origin: US
Product Depth: 28"
Product Height: 2.75"
Product Type: Louvers & Vents
Product Width: 28.5"
Quantity Included: 1
Shipping Weight: 9.6 lbs
Manufacturer Part Number: 556-STD-24
Width: 27 in
Depth: 2-1/2 in
Height: 27 in
Inside Width: 24 in
(No reviews yet) Write a Review
Adding to cart… The item has been added
✔ Fast Shipping · ✔ Secure Checkout · ✔ Made in USA
Questions? We're here to help.
Call 800-810-FILE or email us .
Free Shipping on Qualifying Orders Over $99
Product Specifications:
Country of Origin: US
Product Depth: 28"
Product Height: 2.75"
Product Type: Louvers & Vents
Product Width: 28.5"
Quantity Included: 1
Shipping Weight: 9.6 lbs
Manufacturer Part Number: 556-STD-24
Width: 27 in
Depth: 2-1/2 in
Height: 27 in
Inside Width: 24 in

This automatic exhaust shutter is for facilities using compatible exhaust fans to direct air outward while helping block reverse airflow after the fan stops. Its gravity-closing blades also help shield the opening from environmental elements when airflow is not present.

The rear-flanged shutter has counterbalanced blades that open with horizontal airflow and close by gravity when the fan shuts down. It can be mounted vertically at angles up to 45 degrees and is designed for direct-drive or belt-driven exhaust fans. Do not use it with vane axial or tube axial fans. Overall dimensions are 28 inches wide, 28.5 inches deep, and 2.75 inches high.

Key Features:

  • Automatic blade action: Blades open as airflow begins and close when the fan stops without manual adjustment.
  • Counterbalanced design: Supports vertical mounting at angles up to 45 degrees.
  • Rear flanges: Provide added weather protection around the shutter ends.
  • Reverse-airflow control: Helps prevent air from moving back through the opening after exhaust airflow stops.
  • Compatible fan applications: Works with direct-drive and belt-driven exhaust fans.

Choose this 24-inch exhaust shutter for compatible direct-drive or belt-driven exhaust fan installations that need automatic airflow control and gravity closure.

Country of Origin: US
Product Depth: 28"
Product Height: 2.75"
Product Type: Louvers & Vents
Product Width: 28.5"
Quantity Included: 1
Shipping Weight: 9.6 lbs
Manufacturer Part Number: 556-STD-24
Width: 27 in
Depth: 2-1/2 in
Height: 27 in
Inside Width: 24 in
Inside Height: 24 in
Max Pressure In W.G.: 1 in
Max Velocity (per Minute): 2500 ft/min
Rough Opening: 24-1/2 X 24-1/2 in
Brand: Air Conditioning Products
Finish: Mill Finish
Flange Style: Rear Flange
Manufacturers Part Number: 556-STD-24
Material: Aluminum/Galvanized Steel
Mounting Location: Vertical
Mounting Position: Vertical
Type: Gravity Shutters
Width: 28.00 in
Height: 2.75 in
Depth: 28.50 in
!
